$169.98

8-Band: 160, 75/80, 40, 20, 17, 12, 10, & 6 meters. 270 feet (90+180) long.



Can be used as a off center fed shortwave antenna to provide continuous coverage from 500 kHz to 60 MHzSWL


Quickly switch bands and eliminate a tuner as one more thing to adjust. Eliminate send/receive tuner loss.

Due to the fact that one wire leg of the antenna is shorter than the other, the OCF is more convenient to erect than a regular center fed dipole. Less coax is required.

Check the SWR always BEFORE using with any antenna tuner.

The dipole is constructed using top quality, FLEX-WEAVE TM is a sophisticated hybrid aerial wire. Its new innovation provides rope lay construction strength and high flexibility. It can be tied in knots to insulators and untied for repeated use.

FLEX-WEAVE TM is sometimes referred to as "wire rope" or "jewelers rope". It will not kink or rust out as will copper-clad wire. This flexible wire has also been used for rapid deployment, spool-out, military aerials.



 FLEX-WEAVE TM  #12 (268 strands of #36 wire).  It is excellent for quads, dipoles, long wires, and rapid deployment (spooled-out) antennas. Highly UV resistant PVC jacket.



 FLEX-WEAVE TM is the "Cadillac of aerial wire". It has been written about in all amateur radio publications since its introduction in 1989. This revolutionary product has been used by thousands of hams, commercial firms, and government agencies.



The insulation has superior abrasion resistance for running through trees and is UV and weather resistant for use on the seacoast or in other harsh environments. They'll stand up to acid rain, high wind loads, and high snow and ice loads.





The W2AU is the preferred Balun of Amateurs worldwide. W2AU’s operate at a low VSWR from 1.8 to 40 mHz, and handle powers up to 2 KW PEP (at SWRs of less than 3:1). W2AU Baluns are transformer designs with ferrite cores to provide 95% minimum coupling efficiency. Each has a built-in lightning arrestor, hang up hook, and 600 lbs of pull-apart strength in a weatherized, rugged package using only stainless steel hardware and quality materials. Two models are available. The 1:1 matches 50(75) ohms unbalanced coax to 50(75) balanced dipoles. The 4:1 matches 50(75) ohm unbalanced coax to 200(300) ohm folded dipoles.



No trimming - fully assembled, complete and ready to go with end insulators and crimped center and end connections.

Add your 50 Ohm coaxial feed line, suspension rope and go



Can be hung Flat or inverted V configuration.     Remember stay away from power lines.

Current Stock:
SKU:
NI4L OCF 160-6 FW
Weight:
5.00 LBS
Width:
12.00 (in)
Height:
11.00 (in)
Depth:
4.00 (in)
Shipping Cost:
Calculated at Checkout

Reviews Hide Reviews

windom antenna

Anthony Wingers WA9FKB on 12th May 2017

This is a fine piece of equipment and well constructed of durable materials. It will be a welcome addition to my station.

well builted and easy to set up

george marlow KE0GXQ on 22nd Dec 2015

had it up and working in less than 5 hrs. buy my self

sends and receives great 6-160

Jeff Shifflett on 4th May 2014

Well made easy to install and worked great the first time. Very pleased. Quick service. OCF 8 bands 160-6 HF windom antenna

Windom

Dave on 26th Sep 2013

Very seamless order & shipping was quite fast. Antenna looks to be very well put together from high quality components. I do not have it up yet but plan to soon.
