3 Band OCF
4 Band OCF
7 Band OCF
8 Band OCF

Product Information






3-Band : 20, 12, 10 meters 33 feet (22+11) long.
4-Band:  40, 20, 10, 6 meters 66 feet (45+21) long.
7-Band: 75/80, 40, 20, 17, 12, 10, & 6 meters 135 feet (45+90) long.
8-Band: 160, 80, 60, 40, 20,12, 10, 6 meters  270 feet (180+90) long.


Dual core 240/61 balun 1500 watts RTTY 3KW ICAS.



CURRENT BALUN



  • Each balun and antenna is hand crafted, built right here in the USA.
  • Using the best materials.
  • The ferrite cores are 2 1/4" in dim. using 240/61 material. Teflon wire.
  • It is encased in 3 inch pvc round tubing.
  • Stainless steel hardware is used.
  • Double aluminum ferrals are used to hold the wire in place on the balun double machine crimped.
  • Poly Stealth 13

Can be used as a off center fed shortwave antenna to provide continuous coverage from 500 kHz to 60 MHzSWL


Quickly switch bands and eliminate a tuner as one more thing to adjust. Eliminate send/receive tuner loss.

Due to the fact that one wire leg of the antenna is shorter than the other, the OCF is more convenient to erect than a regular center fed dipole. Less coax is required.

Check the SWR always BEFORE using with any antenna tuner.



The dipole is constructed using top quality,  Poly-STEALTH ™ 13 Breaking strength 370 lbs.
High Strength Aerial Wires are manufactured with high strength, high conductivity Bare Copper-Clad Steel (BCCS) and insulated with a high quality UV Resistant Polyethylene to provide you with one of the strongest and longest lasting antenna wires on the market today.



Advantages to Poly-STEALTH ™ High Strength Aerial Wires: Ideal balance of strength and flexibility Low-Gloss finish and small size makes wire disappear into the background Superior abrasion resistance for running through trees UV & Weather resistant for use on the seacoast or in other harsh environments subjected to acid rain, high wind, or high snow and ice loads.





 NOTE: Some bands will require the use of a tuner. Do not try to load 80 meters with a outboard tuner on the 160 OCF if the SWR is high it will result in damage to the cores and your equipment.

No trimming - fully assembled, complete and ready to go with end insulators and crimped center and end connections.

Add your 50 Ohm coaxial feed line, suspension rope and go



Can be hung Flat or inverted V configuration.     Remember stay away from power lines.

Current Stock:
Shipping Cost: Calculated at Checkout
Weight: 5.00 LBS
Width: 8.00
Height: 12.00
Depth: 3.00
SKU: OCFDC3KW

Customer Reviews 5 (7 Reviews) Write a review of this product

5 Stars
• 7 band OCF Windom Dual core Current balun 3KW Poly-Stealth

Arrived about 2 weeks following order. Erected immediately with balun hung 30' high on a "messenger" hung perpendicularly to antenna, between two trees. (90 ft leg at zero degrees downward, 45 ft leg about 30 degrees downward. The first 40 ft of coax in RX8 for reduced weight, terminating at a grounded lightning arrester. Another 30 ft of RG8U completes the run to the TS590s. Another 65' OCF dipole crosses a couple of feet above the new one at right angles, following the messenger line. I tested and compared both antennas during winter field day., plus some digital work. The new dipole tuned up 1:1 on 80,40,20,17,15,12,10 and 6m , but not 160 or 30m. It seemed to work fine for about 320 of the 360 degree radius . The older windom at right angles would do better only for stations located at less than 20 degrees from the alignment of the new windom. (Old shorter windom will tune up on 30m. ) I'm happy that I can operate the new windom with the skewed inverted V (ie- only the 45 ft leg is "inverted"). So, so far, so good. Good value! Tnx, 73, Eric WA2AIC

5 Stars
OCF Windom Dual Core Current Balun 3KW Poly-Stealth

The antenna was delivered as discussed, well packaged and quality products. It went up easy into the air and I have been making contacts all over the US and DX stations. Excellent customer service and very well made. I plan to purchase more products from here.

5 Stars
8 band ocd windom

Excellent workmanship. Premium components. I also bought th G5RV. Both antennas exceeded my expections.

5 Stars
review

This is my second OCF from NI4L. The quality and workmanship is great and I think it performs well. I can tune all bands with the internal tuner on my FT-950, not true of some other OCFs.

5 Stars
Ant.

Very well pleased with this product I will be ordering more from this guy..

5 Stars
2nd OCF antenna purchased hete!

This is my second 7 band OCF antenna purchased here. The first one I put up 3 weeks ago st 35 foot center inverted V. Upon checking the antenna with my antenna analyzer I found the SWR across all bands to be very low. OK now for the real test. Went to the shack and verified the SWR readings on my Powrr Master 2 meter . OK still very low on all bands. I fired up the Flex 5000 and AL82 and started making contacts on all 7 bands. Great reports. Antenna hears really good and works well when transmitting!! I ordered a second OCF antenna for my permanent campsite. I will be installing it in the spring when the campground opens. Great antenna that I highly recommend !!!

4 Stars
Well done

I gave it a 4 star instead of a 5 star only because I have not actually used it yet. I bought it as a secondary antenna so was not too concerned about it, but I found the quality of materials and construction to be top notch. A windom is a windom so I know what to expect in performance but this is much better made than I was expecting for the money.
